Automatic Tire Changer with Tilt Column and Helper Arm
This automatic tire changer features a tilt column design and a right helper arm. It is capable of handling wheels up to 24 inches in diameter.
Technical Specifications
Product Overview
Automatic Tire Changer with Helper Arm
This high-performance automatic tire changer is engineered for professional automotive service environments. Featuring a pneumatic tilt-back column and an integrated right helper arm, it simplifies the demounting and mounting of stiff, low-profile tires. Built with durable materials including high-strength steel mounting heads and a 40A universal switch, this machine ensures long-term reliability and heavy-load capacity.
Technical Specifications
- Rim clamping (outside)
- 11"-20"
- Rim clamping (inside)
- 12"-24"
- Max wheel diameter
- 950 mm
- Wheel width range
- 3"-12"
Performance
Key Performance Indicators
10 bar
Working Pressure
75 db
Noise Level
1.1 kw
Motor Power
Logistics
Shipping Weights
| Type | Weight |
|---|---|
| Net Weight | 288 |
| Gross Weight | 349 |
Certifications & Support
- Service & Warranty
- 12 Month WarrantyCE CertifiedPneumatic Tilt ColumnIncludes Helper Arm
