Automatic Refrigerant Recovery and Recycling Machine
This machine is designed for automatic refrigerant recovery and recycling. It is designed for use with R134A.
Technical Specifications
Product Overview
Professional Refrigerant Management
This fully automatic refrigerant recovery, recycling, and recharging machine is designed for high-efficiency HVAC and automotive applications. It streamlines the maintenance process by automating recovery, vacuuming, and recharging cycles, ensuring optimal system performance and environmental compliance. Built for professional environments, it features precise electronic scale monitoring and a robust purification system.
Performance Metrics
Recovery Rate (Gas)
450 g/min
Recovery Rate (Gas)
Recovery Rate (Liquid)
800 g/min
Recovery Rate (Liquid)
- Recharging Rate
- 1500 g/min
- Vacuuming Rate
- 170 L/M
Technical Specifications
Compatible Refrigerant
R134A
- Compressor Power
- 3/4 HP
- Vacuum Pump
- 2.5L double stage
- Power Requirements
- 220V, 50/60HZ
Capacity & Precision
- Cylinder Volume
- 35 kg
- Max Recovery Volume
- 28 kgs
- Recharging Range
- 0-26 kgs
- Electronic Scale Precision
- ±2g
Components
Internal Components
- Electronic scale (50kg capacity)
- Double condenser system
- C-162 Filter-Drier
- Patent-pending purification system
