Technical Specifications
Overview
Precision Foam Profiling Solution
This automatic foam profile cutting machine is engineered for the precise creation of complex sponge shapes and profiles. Designed for high-volume production environments, it features automated feeding and adjustable cutting parameters to ensure consistent results across various foam densities. Its robust construction and integrated control systems provide a reliable, efficient solution for industries ranging from furniture and automotive to packaging and insulation.
Technical Specifications
Cutting Speed
30 m/min
Max Cutting Speed
Blade Dimensions
- KX-114: L9000mm x W30mm x T0.45mm
- KX-114B: L9700mm x W30mm x T0.45mm
- Profile Roller Speed
- 30 r/min
- Cutting Type
- Automatic + Feeding Table
Model Comparison
Model Specifications
| Feature | KX-114 | KX-114B |
|---|---|---|
| Foam Width | 1800mm | 2150mm |
| Profiling Depth | 30mm | 30mm |
| Total Motor Power | 8.94kw | 9.94kw |
| Machine Weight | 2100kg | 2300kg |
| Floor Space (LxWxH) | 4300x1250x1500mm | 4500x1300x1500mm |
Applications
- Suitable Industries
- FurnitureAutomotivePackagingInsulation
