Air to Water Heat Pump with EVI Technology
This air to water heat pump utilizes EVI technology for efficient operation in cold climates down to -35℃. It provides both heating and cooling and can be matched with fan coil or floor radiator heating.
Technical Specifications
Overview
High-Efficiency EVI Heat Pump
This air-to-water heat pump system is engineered for exceptional performance in extreme climates, operating effectively in temperatures as low as -35°C. Utilizing Enhanced Vapor Injection (EVI) technology, it delivers superior heating efficiency compared to standard heat pumps, making it an ideal solution for villas, hotels, and offices. The system supports versatile applications including fan coils, floor radiators, and central air conditioning, providing both heating and cooling capabilities.
Performance Metrics
Cooling Performance
53 KW
Cooling Capacity
3
COP
Normal Heating (A7W45)
63 KW
Capacity
3.9
COP
Low-Temp Heating (A-12W41)
37.5 KW
Capacity
2.5
COP
Technical Specifications
Protection Grade
IPX4Class I
- Ambient Temperature Range
- -35 to +43 °C
- Power Supply
- 380V 3N~50Hz
Features & Compatibility
Key Features
- EVI Technology
- 75% Energy Saving
- Automatic Defrost
- Mechanical Antifreeze
- Multiple Protection Systems
- Timed Start Functionality
- Compatible Systems
- Fan CoilFloor HeatingRadiatorCentral Air Conditioning
Compliance & Certification
- Certifications
- CECBSAAGSErPNFSGSROHSSASO
