Adjustable Scoring Saw Blade
Tungsten carbide tipped circular saw blade designed for scoring applications. The body features heat treatment for enhanced durability and performance.
Technical Specifications
Product Overview
High-Precision Adjustable Scoring Blades
These Tungsten Carbide Tipped (T.C.T.) adjustable scoring saw blades are engineered for creating clean, chip-free cuts in industrial applications. Designed for superior longevity, the blades feature a heat-treated body that ensures high stability and reliable performance under demanding conditions. The adjustable width capability provides users with precise control over scoring depth, making them a versatile choice for professional woodworking and manufacturing environments.
Technical Specifications
Geometry Specs
15 deg
Cutting Angle
10 deg
Clearance Angle
12,000 RPM
Max Speed
- Finishing Options
- Teflon® CoatedOriginal
Performance Data
Dimension and Configuration Reference
| Code | Diameter (mm) | Thickness (mm) | Teeth (Z) | Bore (mm) |
|---|---|---|---|---|
| KHC1-100 | 100 | 3.6 | 10+10 | 20 |
| KHC1-100 | 100 | 3.6 | 12+12 | 22 |
| KHC1-120 | 120 | 3.6 | 12+12 | 20 |
| KHC1-125 | 125 | 3.6 | 12+12 | 22 |
| KHC1-120 | 120 | 3.6 | 14+14 | 22 |
Safety
Operating Requirements
- Always use with proper blade guard in place
- Wear appropriate safety glasses during operation
- Inspect blade for cracks or damage prior to use; do not use if damaged
- Always follow the instructions and warnings provided in the saw owner's manual
- Failure to follow safety instructions may result in serious bodily injury
