7-Ton Diesel Forklift with Isuzu Engine
This 7-ton diesel forklift is equipped with a reliable Isuzu engine. It is designed for heavy-duty material handling in warehouses, rental facilities, logistics centers, and factories.
Technical Specifications
Product Overview
High-Efficiency 7-Ton Diesel Forklift
This 7-ton diesel forklift is engineered for high-performance material handling in demanding industrial environments like logistics centers and factories. Powered by a reliable engine and featuring an electronic hydraulic transmission, it balances raw power with precise control. The design prioritizes operator comfort with a new suspension system and adjustable seating to reduce fatigue during long shifts.
Core Performance
Lifting Performance
7,000 kg
Rated Capacity
3,000 mm
Max Lifting Height
600 mm
Load Center
Operational Speeds
| Activity | Loaded | Unloaded |
|---|---|---|
| Lifting Speed | 450 mm/s | 500 mm/s |
| Lowering Speed | 500 mm/s | 450 mm/s |
| Travelling Speed | 25 km/h | 30 km/h |
Engine & Transmission
- Engine Model
- 6BG1
- Transmission
- Electronic hydraulic transmission
- Fuel Tank Capacity
- 135 L
Design & Ergonomics
Operator Comfort & Safety
- New suspension system with adjustable seat
- Expanded step area (1.5x standard) with lower height
- Embedded LCD instrument with neutral start protection
- Double protection type brake lever
- Plastic ceiling for all-weather overhead protection
- Single chain mast design for enhanced front visibility
Maintenance
Maintenance Accessibility
- Removable side cover for easy inspection
- Integrated control box for fuses and relays
- Aluminum heat sink for enhanced cooling efficiency
- Large double muffler for superior noise reduction
Dimensions & Chassis
- Overall Length (with fork)
- 4870 mm
- Overall Width
- 2000 mm
- Turning Radius
- 3370 mm
- Tire Configuration
- Pneumatic (4 Front / 2 Rear)
- Total Truck Weight
- 9200 kg
Certifications
- Standards & Compliance
- ISO 9001:2015CE CertifiedGB/T 19001-2016
