5.5kW Portable Gasoline Generator
This 5.5kW gasoline generator delivers consistent power for diverse applications. It features safety controls, a durable frame, and a 420cc engine.
Technical Specifications
Product Overview
Reliable 5.5kW Portable Power Solution
The BS6500 series is a robust 5.5kW gasoline generator designed for both residential and commercial applications. Featuring a high-displacement 420cc engine and a large 25-liter fuel tank, it provides up to 9 hours of continuous operation. The unit is built into a protective frame for enhanced durability and portability, making it an ideal choice for dependable power in diverse environments.
Key Performance Metrics
Performance Highlights
5.5 kW
Maximum Power
420 cc
Displacement
9 h
Continuous Run Time
25 L
Fuel Capacity
Engine Specifications
Engine Details
| Feature | Specification |
|---|---|
| Engine Type | Single cylinder, 4-stroke, OHV 25 |
| Cooling System | Forced air cooling |
| Oil Capacity | 1.1 L |
| Speed | 3000/3600 rpm |
| Starting System | Recoil / Electric Start |
Electrical Output
Electrical Specifications
- Rated Voltage: 110/220/380V
- Rated Current: 22.7A
- Frequency: 50/60Hz
- AVR (Automatic Voltage Regulator) included
- Integrated Voltmeter and Circuit Breaker
Physical Attributes
Dimensions & Weight
| Metric | Value |
|---|---|
| Dimensions | 700 x 540 x 580 mm |
| Net Weight | 74 kg |
| Gross Weight | 76 kg |
Compliance & Logistics
- Certifications
- CEEuro-V
- Container Loading
- 136 units (20GP) / 292 units (40HQ)
