Technical Specifications
Overview
Reliable Portable Power Solution
This 3kW gasoline generator is engineered for professional and domestic backup power, featuring a robust 170F single-cylinder OHV engine. Equipped with an Automatic Voltage Regulator (AVR) and a 100% copper wire alternator, it ensures stable electricity delivery for sensitive electronics. The portable design includes a unique dismountable external battery bracket, facilitating easier packaging and logistics for international shipping.
Performance Highlights
Key Performance Metrics
3 kW
Max Output
2.8 kW
Rated Output
230 V
Rated Voltage
15 L
Fuel Capacity
- Fuel Consumption
- 395 g/kw.h
Engine Specifications
Engine Details
| Feature | Specification |
|---|---|
| Engine Model | 170F |
| Type | Single-cylinder, OHV 25° inclined, 4-stroke, air-cooled |
| Displacement | 212 ml |
| Max Torque | 11.5 N.m / 2500 rpm |
| Starting System | Recoil Start |
Electrical & Control
Alternator Construction
100% Copper WireBrushSingle Phase
- Voltage Regulation
- Automatic Voltage Regulation (AVR)
- Digital Indicator
- Three-in-one display for voltage, frequency, and working time
Physical Characteristics
- Dimensions (L*W*H)
- 600 x 445 x 455 mm
- Weight (Net/Gross)
- 45 / 47 kg
- Socket Style
- European-style
Compliance & Safety
- Standards & Certifications
- CETÜV SUDGSEURO-IIEMCSONZHB
Logistics
Container Loading Capacity
- 20'GP: 240 sets
- 40'HQ: 485 sets
- Battery Bracket Design
- External dismountable structure for 17A+ batteries to optimize packaging
