300cc Off-Road Dirt Bike
This off-road dirt bike features a robust 300cc engine, delivering ample power and torque for challenging terrains. Advanced suspension systems provide excellent handling and control.
Technical Specifications
Overview
High-Performance Off-Road Engineering
Designed specifically for skillful riders, this 300cc off-road motorcycle combines power with precision handling. It features a water-cooled engine with an internal balance shaft to minimize vibration, paired with a lightweight, high-strength forged alloy frame. With fully adjustable suspension and aerodynamic plastics, this bike is engineered to deliver agility and control across challenging terrains.
Engine & Performance
Engine Specifications
300 CC
Displacement
18.5 kW
Max Power
8,500 r/min
Rated RPM
Technical Details
| Feature | Specification |
|---|---|
| Engine Type | 4-stroke, water cooling |
| Bore & Stroke | 74 x 65 mm |
| Starting Mode | Electric/Kick start |
| Transmission | 5 gear |
| Carburetor | PE28 |
Chassis & Suspension
Suspension System
- Front: 53/58.5-910mm fork, compression & rebound damping adjustable
- Rear: 480mm shock with external air bag, compression & rebound damping adjustable
- Frame Construction
- Forged Alloy FrameReinforced TubeForged Alloy Swing Arm7XXX Alloy Fat Bar
Wheels & Brakes
Wheel & Tire Configuration
| Position | Rim Size | Tire Size |
|---|---|---|
| Front | 1.60-21 | 80/100-21 |
| Rear | 2.15-18 | 100/90-18 |
- Braking System
- Disc brakes, 240mm diameter (front and rear)
Dimensions & Capacity
Weight & Load
117 kg
Net Weight
90 kg
Max Loading
- Dimensions
- 2140 x 820 x 1240 mm
- Fuel Capacity
- 6.5 L
