3-Ton Diesel Forklift with Side Shift
This 3-ton diesel forklift is designed for efficient operation in containers and warehouses. It features a side shift attachment for precise load positioning.
Technical Specifications
Overview
High-Efficiency 3-Ton Diesel Forklift
This 3-ton diesel forklift is engineered for high efficiency and energy saving, making it an ideal choice for demanding warehouse and container operations. It features a radical design innovation that prioritizes the needs of managers and drivers alike, incorporating a side shift attachment for precise load positioning in confined spaces. With a focus on durability and reliability, this model integrates advanced hydraulic technology and ergonomic features to ensure comfortable, long-term operation.
Key Performance Metrics
Performance Highlights
3,000 kg
Rated Capacity
3,000 mm
Max. Lifting Height
19 km/h
Travel Speed (Loaded)
21 %
Max. Gradeability
Technical Specifications
- Power Unit
- Diesel
- Transmission
- Electronic hydraulic transmission
- Load Center
- 500 mm
- Turning Radius
- 2400 mm
Operational Performance
Lifting & Lowering Speeds
| Operation | Loaded (mm/s) | Unloaded (mm/s) |
|---|---|---|
| Lifting Speed | 500 | 550 |
| Lowering Speed | 480 | 450 |
Dimensions & Weight
Chassis Dimensions
- Overall Length (without fork): 2705 mm
- Overall Width: 1240 mm
- Overhead Guard Height: 2130 mm
- Mast Height (Fork lowered): 2140 mm
- Total Truck Weight
- 4380 kg
- Fork Size (L×W×T)
- 1220 × 125 × 45 mm
Operator Comfort & Safety
- Safety & Ergonomics
- Adjustable Suspension SeatLCD Instrument DisplayNeutral Start ProtectionDouble Protection Brake LeverOverhead Guard Plastic CeilingAnti-Slip Step AreaEnhanced Front View Mast
Maintenance & Design
Design Advantages
- Removable side cover for easy engine inspection
- Integrated control box for fuses and relays
- Aluminum heat sink for enhanced cooling effect
- Large double muffler for superior noise reduction
- Sunken tilt cylinder for increased floor space
Compliance
Quality Standards
ISO 9001:2015CE Certified
