Technical Specifications
Overview
Reliable Portable Power
This 2kW open frame gasoline generator is a versatile power solution designed for construction sites, emergency backup, and recreational use. Featuring a robust 4-stroke, air-cooled engine, it delivers consistent performance with both manual and electric start options. The unit includes comprehensive AC and DC output options to support a wide range of electrical devices and tools.
Electrical Output
Rated Output
2 kW
Rated Output
2.2 kW
Max Output
- Voltage Configurations
- 220V/380V110V/220V
- AC Frequency
- 50Hz/60Hz
- DC Output
- 12V / 8.3A
Engine Specifications
Engine Details
| Feature | Specification |
|---|---|
| Displacement | 163cc |
| Horsepower | 5.5 HP |
| Cooling System | Air-cooled |
| Stroke | 4-stroke |
Starting System
Manual StartElectric Start
Capacity & Maintenance
- Fuel Tank Capacity
- 15 L
- Oil Capacity
- 0.6 L
