Technical Specifications
Product Overview
Industrial Grade Performance
This 230x6x22mm grinding wheel is a high-performance abrasive tool engineered for demanding industrial applications. It features a resinoid bond with fiberglass reinforcement for enhanced durability and safety during operation. Designed for precision and efficiency, it provides excellent material removal rates on a variety of metallic surfaces.
Technical Specifications
Maximum Operating Speed
80 m/s
Velocity
6,640 RPM
Rotation
Material Construction
- Resinoid bond
- Fiberglass reinforcement
- Alumina oxide
- White alumina oxide
- Dimensions
- 230 x 6.0 x 22.23 mm
Safety and Compliance
- Certifications & Standards
- EN 12413ANSI B7.1ISO 9001
Application
Suitable Materials
| Material Type | Abrasive Type |
|---|---|
| Carbon steel, annealed iron, hard bronze | Alumina oxide |
| Hardened/alloy/stainless/high-carbon steels | White alumina oxide |
