21.5-inch Digital Signage with Sanitizer and Temperature Monitoring
This digital signage unit features a 21.5-inch display with an integrated sanitizer dispenser and temperature monitoring system. It offers advertising capabilities alongside essential hygiene functions, making it ideal for public spaces.
Technical Specifications
Overview
Smart Health & Advertising Station
This 21.5-inch all-in-one digital signage solution integrates intelligent temperature monitoring, automated hand sanitization, and high-definition advertising capabilities. Designed for high-traffic public environments, it features non-contact infrared sensing for precise temperature checks and a smart dispenser for hygienic hand care. The unit supports remote content management, making it an effective tool for both health screening and informational broadcasting.
System Hardware
- Processor
- RK3288 Quad-core 1.8GHz
- RAM
- 2 GB
- Internal Storage
- 8 GB
- Supported Expansion
- 16GB32GB64GB128GB
Display Specifications
Display Performance
1,920 px
Resolution Width
1,080 px
Resolution Height
350 cd/m2
Brightness
6 ms
Response Time
Screen Details
- 21.5 inch LED Panel
- IPS Full Viewing Angle
- 1000:1 Contrast Ratio
Health Monitoring
Supported Dispensing
SprayFoamSoap Drops
- Temperature Range
- 23-48 degrees Celsius
- Measurement Distance
- 30-50 cm
- Sanitizer Capacity
- 1000 ml
Connectivity & Software
Software Capabilities
- PC Information Release Software
- Mobile App Support
- WeChat Applet Integration
- LAN/Cloud Deployment
- Physical Interfaces
- USB 3.0USB 2.0RJ45WIFI
Physical & Power
- Power Consumption
- 18 W
- Build Materials
- Full sheet metal, tempered glass, nano anti-fouling coating
