200cc Off-Road Dirt Bike
This 200cc dirt bike is designed for versatile off-road adventures. It features long-travel suspension, knobby tires, and a robust frame for optimal traction and durability on various terrains.
Technical Specifications
Overview
Versatile 200cc Off-Road Performance
This 200cc off-road dirt bike is engineered for agility and reliability on challenging terrains. Featuring a robust 199.1cc, 4-stroke air-cooled engine and a 5-speed transmission, it balances power and control for a wide range of riders. With durable suspension, responsive disc braking, and knobby tires, it is built to handle bumps and loose surfaces with ease.
Engine & Performance
Maximum Power
11.5 kw
Max Power
Engine Technical Details
| Feature | Specification |
|---|---|
| Type | Single-cylinder, 4-stroke, air-cooled |
| Bore x Stroke | 66 x 58.2 mm |
| Compression Ratio | 9.4:1 |
| Ignition | CDI |
| Starting System | Electric |
- Engine Displacement
- 199.1 cc
Drivetrain & Chassis
Suspension Setup
- Front: Spring oil damper
- Rear: Swing-arm spring oil damper
Braking System
- Front: Disc type
- Rear: Drum type
- Transmission
- 5-speed gear shift
- Drive Type
- Chain
Dimensions & Capacity
- Dimensions (L x W x H)
- 2120mm x 800mm x 1180mm
- Dry Weight
- 118 kg
- Fuel Tank Capacity
- 10.6 L
Logistics & Options
Available Colors
Red/YellowBright RedApple GreenMiddle YellowDeep Blue
Shipping & Packing
| Metric | Details |
|---|---|
| Packing Size | 1890 x 460 x 1050 mm |
| 40' GP Capacity | 60 units |
| 20' GP Capacity | 30 units |
| 40' HQ Capacity | 110 units |
