2-Gang Stainless Steel Switched BS Socket
This 2-gang switched socket features a stainless steel faceplate for durability. It is equipped with a double pole switch and a protective door to prevent electrical shock.
Technical Specifications
Overview
Premium 2-Gang Switched Socket
This 2-Gang Stainless Steel Switched BS Socket combines a sleek, brushed finish aesthetic with robust safety features, including a protective door design to prevent electric shock. Engineered with high-temperature resistant materials for switch buttons and housing, it is ideal for demanding environments such as schools, hotels, and modern residential buildings. The double-pole switching functionality ensures enhanced electrical safety for international B2B applications.
Key Performance Metrics
Key Performance Metrics
13 A
Rated Current
250 V
Rated Voltage
850 ℃
Flame Retardancy
Technical Specifications
Number of Gangs
- 2 Gang (Standard)
- 1 Gang (Available)
- Device Type
- Plug Socket
- Product Series
- W86A series
- Network Frequency
- 50/60Hz
Design & Materials
Material Composition
| Component | Material |
|---|---|
| Cover Frame | Brushed finish stainless steel |
| Switch Paddle & Insert | Polycarbonate (PC) |
| Chassis | High polymer PC with glass fiber |
| Base | PA Nylon |
| Contacts | Brass |
Installation
- Mounting Type
- Flush wall mounted
- Dimensions
- 86*147mm
- Embedding Depth
- 25 mm
- Connection Type
- Screw terminals (pillar terminal) M3*6.5mm
Safety & Standards
IP Rating
IP20
Safety Features
- Child-protective door design
- Double pole switching
- High temperature resistant housing
- Concealed fixing screws
- Compliance Standards
- BS 1363-2CECBTUV
Quality Assurance
- Management Certifications
- ISO 9001:2015ISO 14001:2015ISO/IEC 17025
Application
Recommended Applications
- Industrial Facilities
- Hotels & Clubs
- Commercial Offices
- Residential Buildings
- Schools
