Technical Specifications
Product Overview
High-Performance Brushless 12V Cordless Drill
This 12V cordless drill features an advanced brushless motor (BLDC) designed for enhanced performance, extended runtime, and superior durability. Its compact, slim design combined with a lightweight 0.9kg body makes it ideal for prolonged use in tight spaces. Equipped with a 2.0Ah lithium-ion battery and an imported control chip, it offers professional-grade reliability for a wide range of drilling and fastening applications.
Performance Metrics
Key Performance Metrics
30 N.m
Max Torque
1,400 r/min
Max Speed
10 mm
Collet Diameter
40 Min
Charging Time
Technical Specifications
Technical Data
| Parameter | Value |
|---|---|
| Model | BL7212-20C |
| No-Load Speed (Low/High) | 0-400 / 0-1400 r/min |
| Torque Settings | 15+1 Shelves |
| Weight (with battery) | 0.9 kg |
| Dimensions (Height/Width) | 18cm x 19cm |
Drilling Capacities
Maximum Drilling Diameter
- Steel: 10mm
- Wood: 25mm
Battery & Power
Battery Details
- Voltage: 12V
- Capacity: 2.0Ah
- Type: Lithium-ion
- Protection: PI Chip to prevent overcharge
- Fast Charging: ~40 minutes
Advanced Features
- Safety & Control
- Overload ProtectionOverheat ProtectionLow Voltage ProtectionStepless SwitchBrushless MotorLED Auto Delay
Applications
Recommended Applications
Furniture AssemblyTerminal Block InstallationMaintenanceMetal DrillingPlastics DrillingWood DrillingCeramic TilesWall Drilling
Design & Ergonomics
Design Highlights
- Slim design for tight spaces
- Soft grip handle with two-level adjustment
- 15-second delay LED light for dark areas
- Lightweight portable construction
- Easy bit installation/uninstallation
