Wedge Wire Water Well Screen
This wedge wire water well screen is constructed with rods and triangular wire for a robust structure. It has a large open area and precise slot dimensions for efficient medium filtering.
Technical Specifications
Product Overview
High-Performance Wedge Wire Well Screens
These V-wire wedge wire screen pipes are engineered for superior filtration in water, oil, and gas wells. Constructed with a robust structure and precise slot dimensions, they offer excellent anti-corrosive properties and heat resistance. The design maximizes open area to enhance well efficiency, reduce pump abrasion, and extend the overall service life of your well infrastructure.
Technical Specifications
Technical Dimensions
| Component | Specification Range |
|---|---|
| Wire Width | 1.50mm - 3.70mm |
| Wire Height | 2.20mm - 6.30mm |
| Support Rod Width | 2.30mm - 3.70mm |
| Support Rod Height | 2.70mm - 6.30mm |
| Support Rod (Round) | 2.50mm - 6.0mm |
| Diameter | 25mm - 800mm |
| Max Length | Up to 6 meters |
Material & Construction
End Connections
- Plain beveled ends for butt welding
- Threaded
- Available Materials
- Low Carbon SteelGalvanized Steel (LCG)Stainless Steel 304Stainless Steel 316
Performance Features
Performance Metrics
0.1 mm
Minimum Slot Size
6 mm
Maximum Slot Size
Key Advantages
Anti-corrosiveHeat-resistantAnti-cloggingHigh open areaEasy backwashing
