Wedge Wire Screen for Water Wells
These screens are engineered for efficient water or fluid intake while preventing sand or gravel from entering the well. The continuous slot design minimizes clogging and facilitates easy cleaning, making them a reliable choice for demanding filtration applications.
Technical Specifications
Product Overview
High-Efficiency Wedge Wire Screens
These wedge wire screens are engineered for superior fluid-solid separation in water well, oil, and gas applications. Utilizing a V-shaped profile wire, the design ensures continuous slot openings that minimize clogging by allowing only two-point contact for particles. This robust construction maximizes effective flow area, reduces pressure drop, and provides exceptional resistance to corrosion and high-pressure environments.
Technical Specifications
Performance Benefits
- Higher capacity
- Reduced maintenance requirements
- Exceptional wear life
- Lower pressure drop
- High resistance to corrosion and temperature
Example Dimensions
9.625 inches
Diameter
5,850 mm
Length
- Key Design Features
- V-shaped profile wireContinuous slot openingsHigh-strength welded constructionAnti-clogging design
Materials & Compatibility
Material Composition
Stainless SteelCarbon SteelCorrosion-resistant Alloys
Applications
Primary Applications
- Water wells
- Oil and gas wells
- Environmental filtration
- Sand and gravel control
