Water Well Screen Tubes
Screen well screen tubes are designed for water well applications. The wedge wire design provides a large open area, minimizing head loss and maximizing well efficiency for reliable and efficient water extraction.
Technical Specifications
Overview
High-Performance Wire-Wrapped Well Screens
These wire-wrapped stainless steel well screen tubes are engineered for superior filtration and structural integrity in water well applications. Featuring a continuous V-shaped slot design, they maximize open area to significantly reduce frictional head loss and improve pump efficiency by 20-25%. Constructed from corrosion-resistant stainless steel, these screens offer exceptional durability, sand control, and reliability for long-term subsurface use.
Technical Specifications
Connection Styles
WeldedThreaded Male CouplingThreaded Female Coupling
Standard Lengths
- 1m
- 5.85m
- Material Options
- 302 Stainless Steel304 Stainless Steel304L Stainless Steel316 Stainless Steel316L Stainless Steel
- Slot Opening Range
- 0.05mm - 0.15mm (and wider)
- Filtration Direction
- Outside to inside
Performance Metrics
Performance Benefits
25 %
Power Saving Potential
2 x
Open Area Increase (vs conventional)
Design Features
Key Design Features
| Feature | Description |
|---|---|
| Slot Shape | V-Shaped (prevents clogging) |
| Construction | Resistance welded profile wire on support rods |
| Rod Types | Round, Triangular, or Trapezoid |
| Surface Wire | Triangular (V-shaped) |
