Wafer Double Check Valve, Cast Iron, ANSI 150LB
This wafer type double check valve is designed for industrial applications requiring reliable backflow prevention. The valve features a cast iron body and stainless steel internals for corrosion resistance and durability.
Technical Specifications
Product Overview
Industrial Wafer Double Check Valve
This Wafer Double Check Valve is engineered for reliable backflow prevention in industrial piping systems. Featuring a compact wafer design, it is easily installed between flanges, making it an efficient solution for space-constrained environments. Constructed with a robust cast iron or ductile iron body and corrosion-resistant stainless steel internals, this valve ensures long-term durability and positive shutoff performance.
Technical Specifications
Material Grades
CF8MSCS13
- Pressure Rating
- ANSI 150LB
- Available Sizes
- DN50 - DN600
- Standard
- American Standard
Materials
- Body Material
- Cast Iron / Ductile Iron
- Disc Material
- Stainless Steel ANSI 316L
- Seat Material
- EPDM
- Spring and Stem Material
- Stainless Steel ANSI 316L
Certifications
- Certifications
- ISO 9001TS
