Vertical Multistage Stainless Steel Pump
This vertical multistage pump is constructed from stainless steel for corrosion resistance and durability. Its close-coupled design allows for compact installation and efficient operation in a variety of applications.
Technical Specifications
Overview
High-Performance Vertical Multistage Pump
This vertical multistage stainless steel pump is engineered for demanding industrial and municipal applications, offering robust performance for water supply, pressure boosting, and boiler feed systems. Constructed from high-grade stainless steel, it ensures excellent corrosion resistance and long-term durability in diverse environments. Its compact, close-coupled design maximizes installation flexibility, making it an ideal solution for systems requiring high pressure and efficient fluid transfer.
Performance
Maximum Capacity
970 USGPM
Max Capacity
240 m3/h
Max Capacity
- Maximum Head
- 300 m
Operating Conditions
Rotation Speed Options
- 2900 rpm
- 1450 rpm
- 3500 rpm
- Max Liquid Temperature
- 120 °C
Construction
Material Specifications
| Component | Material |
|---|---|
| Casing | Stainless steel / Duplex stainless steel |
| Impeller | Stainless steel / Duplex stainless steel |
| Shaft | Stainless steel |
| Wear ring | Stainless steel |
Applications
- Suitable Applications
- Water SupplyCooling SystemsFire ProtectionBoiler FeedIrrigationGeneral Industry
