Vertical Centrifugal Water Pump
This centrifugal single-impeller water pump is designed for flow irrigation systems. It boosts and maintains pressure in domestic water supply systems using water from a well or tank.
Technical Specifications
Product Overview
Efficient Vertical Centrifugal Pump
The Vertical Centrifugal Water Pump is designed for efficient and reliable water circulation in various HVAC&R applications. Its vertical design saves valuable floor space and simplifies installation, while the robust construction ensures long-lasting performance. Equipped with thermal overload protection and a high-performance motor, this pump is ideal for cooling towers, chillers, and general water supply systems.
Technical Specifications
- Model
- LFI1-550
- Voltage
- 115 V
- Power Consumption
- 25 W
- Rated Current
- 0.4 A
- RPM
- 3000 RPM
- Max Head
- 4.5 ft
Operating Limits
- Max. Suction Head
- 8 m
- Max. Liquid Temperature
- 60 ℃
- Max. Ambient Temperature
- 40 ℃
Features
Key Features
- Compact vertical design
- Quiet operation
- Easy installation
- Low maintenance
- Thermal overload protection
- Continuous duty
- Suitable Applications
- HVAC&RCooling TowersChillersWater SupplyIndustrial Processes
