USB 2.0 CMOS Camera for Machine Vision
This high-performance CMOS camera is designed for machine vision and inspection applications. It features a USB 2.0 interface for seamless connectivity and real-time data transfer.
Technical Specifications
Overview
High-Performance Machine Vision Camera
This SD1 Machine Vision and Inspection Camera is engineered for demanding industrial imaging tasks requiring high precision. Featuring a 1.3MP CMOS sensor and a high-speed USB 2.0 interface, it delivers reliable real-time data transfer for automated optical inspection and quality control. With advanced programmable controls and a compact form factor, this camera offers the versatility needed for seamless integration into various machine vision systems.
Imaging Performance
Key Imaging Metrics
1.3 MP
Effective Pixels
44 dB
SNR
71 dB
Dynamic Range
68 FPS
Frame Rate
Sensor Specifications
| Parameter | Value |
|---|---|
| Sensor Model | MT9M111 |
| Pixel Size | 3.6μm × 3.6μm |
| Resolution | 1280×1024 |
| Sensibility | 1.0V/Lux-sec (550nm) |
| Shutter Type | Electronic rolling shutter |
Connectivity & Compatibility
Supported Operating Systems
- Windows XP (32-bit)
- Windows 7 (32-bit)
- Windows 7 (64-bit)
- Connectivity
- USB 2.0TWAINDirectShow
Physical & Environmental
Physical Dimensions
| Component | Measurement |
|---|---|
| Product Dimensions | 44.1 × 43 × 41.5 mm |
| PCB Size | 33 × 33 mm |
| Weight | 123 g |
| Lens Mount | C/CS mount |
Environmental Ratings
0℃ to 50℃ Operating Temp10%-90% RH Humidity
Power & Control
Power Consumption
1.3 W
Work
0.55 W
Standby
