Technical Specifications
Product Overview
Professional Underground Insulation Piercing Connector
The UJBC series is designed for reliable low voltage branch connections in underground cabling systems. Its insulation-piercing technology allows for safe installation without the need to strip cable insulation, significantly improving efficiency. Built with corrosion-resistant materials and UV-resistant components, this connector ensures long-term durability and consistent performance in demanding environments.
Technical Specifications
- Standards
- ANSI C 119.1-2011
- Body Material
- Corrosion-resistant aluminium alloy
- Insulation Material
- Weather and UV resistant polymer
- Required Torque
- 16 N.m
Compatibility
- Compatible Conductors
- CopperAluminium
- Aluminium Range
- 10-150 mm²
- Copper Range
- 2.5-120 mm²
Model Variants
Model Dimensions & Packing
| Model | Length (mm) | Width (mm) | Pack (pcs) |
|---|---|---|---|
| UJBC2.5-150/3P | 94 | 56 | 20 |
| UJBC2.5-150/4P | 122 | 56 | 24 |
| UJBC2.5-150/5P | 151 | 57 | 12 |
| UJBC2.5-150/6P | 178 | 57 | 10 |
Features
Core Advantages
- Shear head bolt for consistent torque
- Pre-filled silicone grease for waterproof insulation
- Visual confirmation window for cable positioning
- Piercing design eliminates stripping
