C-Shaped Copper Bimetallic Wire Terminal Connector
This C-shaped connector is designed for connecting copper conductors to electronic equipment in power cable applications. It is made of high-purity copper and features surface acid-washing.
Technical Specifications
Product Overview
C-Shaped Copper Wire Connector
These C-shaped wire terminal connectors are engineered for high-performance electrical connections, utilizing 99.99% pure T2 copper tubing for superior conductivity. Designed for reliability in power cable and electronic equipment applications, these clamps undergo rigorous surface acid-washing to ensure quality. They are built to withstand demanding environments with an operational temperature range of -55°C to 150°C.
Technical Specifications
- Copper Purity
- 99.9 %
- Operating Temperature
- -55°C to 150°C
- Surface Coating
- Nature ColorTin
Certifications
Compliance & Standards
CEULJISDINAWGRoHSISO 9001:2015IATF16949
Dimensions
Connector Dimensions (mm)
| Item No. | B | D | E | A | C | L |
|---|---|---|---|---|---|---|
| CRC-3 | 10.5 | 18.7 | 6.9 | 6.3 | 7.7 | 17.5 |
| CRC-6 | 15.4 | 25.2 | 9.3 | 9.6 | 9.3 | 21.2 |
| CRC-8 | 18.4 | 33.3 | 11.3 | 11.9 | 11.9 | 27.2 |
| CRC-10 | 22.3 | 42 | 13.1 | 13.2 | 14.8 | 29.2 |
| CRC-11 | 24.8 | 41 | 14.6 | 14.3 | 14 | 29.4 |
| CRC-14 | 31.5 | 44.5 | 15.2 | 15 | 18.6 | 27.5 |
