Three-Roller Metal Sheet Rolling Machine
This three-roller rolling machine is designed for forming metal sheets into cylindrical shapes. It features a control panel for precise adjustments to the roller positions, allowing for accurate control over the curvature of the formed metal.
Technical Specifications
Overview
Precision Metal Rolling Solution
This three-roller metal sheet rolling machine features an advanced asymmetrical structure designed for high-precision bending and shaping. With an independent drive system for each roll via gearboxes, it delivers superior rolling torque and speed without energy loss. The machine's RGS design minimizes the distance between bending points, ensuring exceptional accuracy for cylindrical and conical metal components.
Mechanical Design
Drive System
- Upper roller main drive
- Independent drive for all three rolls
- Direct coupled gearboxes
- Roller Structure
- 3-roller asymmetrical
- Key Design Features
- RGS bending designLinear slide supportLubrication circuitHigh-torque output
Performance
Operational Capabilities
3 units
Number of Rolls
Precision Level
High PrecisionConsistent Curvature
