Three-Phase Automatic Voltage Stabilizer
This three-phase automatic voltage stabilizer provides stable and reliable voltage regulation. It automatically adjusts the output to compensate for fluctuations in the input voltage, ensuring a consistent power supply.
Technical Specifications
Product Overview
Industrial-Grade Automatic Voltage Stabilization
The SBW-F series three-phase automatic voltage stabilizer offers high-precision power conditioning for industrial machinery and sensitive electronic systems. Utilizing advanced servo motor control technology, it ensures consistent output with over 90% efficiency. Engineered with comprehensive protection functions, including over-voltage, low-voltage, and thermal monitoring, this unit provides reliable performance in demanding electrical environments.
Key Features
- Built-in Protections
- Over-voltage protectionLow-voltage protectionOver-heat protectionOver-load protection
Technical Specifications
Core Metrics
90 %
Efficiency
50 KVA
Minimum Power
2,000 KVA
Maximum Power
Input Voltage Range
- Phase voltage: 175V-265V / 154V-286V
- Line voltage: 300V-465V / 270V-490V
Operating Conditions
| Parameter | Value |
|---|---|
| Ambient Temperature | -15°C to 45°C |
| Relative Humidity | < 95% |
| Insulation Resistance | > 2MΩ |
