Three-Phase Aluminum Housing Induction Motor 0.18kW
This three-phase induction motor features a durable aluminum housing, ensuring efficient heat dissipation. It is designed for various industrial applications requiring reliable power generation.
Technical Specifications
Overview
High-Efficiency Aluminum Induction Motor
The MSL series three-phase induction motor is engineered for reliable performance in diverse industrial applications. Featuring a durable aluminum housing, this motor ensures efficient heat dissipation and a long service life. It is designed to operate consistently at 50 Hz, offering a robust solution for machinery requiring stable speed and torque.
Technical Specifications
Power Output
0.18 kW
Power
0.25 HP
Horsepower
Electrical Characteristics
| Parameter | Value |
|---|---|
| Voltage | 230/400V |
| Current | 1.4/0.8 A |
| Frequency | 50 Hz |
| Connection | Δ/Y |
Performance & Durability
Protection Rating
IP55
- Rotational Speed
- 1380 r/min
- Insulation Class
- Class F
- Duty Cycle
- S1
Compliance
- Certifications & Standards
- CEISO9001
- Country of Origin
- China
