Three-Phase 100 kVA Diesel Generator Set
This three-phase diesel generator set delivers 400 volts at 50 Hz with a power factor of 0.8. It is engineered to provide a reliable power source for various applications.
Technical Specifications
Overview
Reliable Three-Phase Power Generation
This 100 kVA diesel generator set is engineered for consistent and dependable power delivery in industrial and commercial environments. Designed for three-phase operation at 50 Hz and 400 volts, it offers a power factor of 0.8, ensuring efficient energy output. The unit is built to withstand demanding conditions, providing both prime and standby power capabilities to meet diverse operational requirements.
Electrical Specifications
Featured Metrics
100 kVA
Rated Power
400 V
Voltage
50 Hz
Frequency
0.8
Power Factor
Available Voltage Configurations
- 415/240V
- 380/220V
- 220/127V
- 200/115V
- 440/254V
- 208/120V
Operational Standards
Duty Cycle Definitions
| Duty Type | Description |
|---|---|
| ESP (Standby Power) | Standby duty, operation under variable load, without overload |
| PRP (Prime Power) | Continuous duty operation, variable load 24/24h, 10% overload permissible 1h/12h |
Ambient Reference Conditions
- 1,000 mbar pressure
- 27°C temperature
- 30% relative humidity
- Compliance Standards
- ISO 3046ISO 8528
