Super Cell Marine Rubber Fender
The super cell marine rubber fender is a second-generation cell type fender with enhanced performance. It offers increased energy absorption and reduces pressure on the ship's side board, making it suitable for large vessels.
Technical Specifications
Product Overview
Super Cell Marine Rubber Fender
The TLT-AA Super Cell Rubber Fender represents a high-performance second-generation solution for modern port infrastructure and vessel berthing. Engineered for superior durability and impact protection, this fender features a specialized design that increases energy absorption by approximately 17% while maintaining efficient reaction force profiles. Enhanced with UHMW-PE cladding, it reduces friction and shear forces during contact, significantly extending the service life of both the fender and the vessel's hull.
Key Features
Performance Benefits
- Increased energy absorption by 17% compared to standard cell fenders
- Improved E/R·H value efficiency by 15%
- Reduced ship-side pressure (below 200KN/㎡) for safer large-vessel berthing
- Minimized friction and shear power via integrated UHMW-PE front panel
- Stable performance during slant compression
Technical Specifications
Dimensions & Weights
| Model | Height (mm) | Weight (kg) |
|---|---|---|
| TLT-AA 500 | 500 | 111 |
| TLT-AA 1000 | 1,000 | 825 |
| TLT-AA 1600 | 1,600 | 3,030 |
| TLT-AA 2000 | 2,000 | 5,030 |
| TLT-AA 3000 | 3,000 | 18,500 |
Operational Limits
52.5 %
Rated Compression Deflection
55 %
Maximum Compression Deflection
10 %
Performance Tolerance
Compliance
- Certifications & Standards
- ISO 9001ISO 14001China Classification Society Approved
