Stationary Diesel Engine for Generators
This diesel engine is turbocharged and inter-cooled for stationary diesel generators. It provides reliable power for various applications.
Technical Specifications
Overview
High-Performance Stationary Diesel Engines
These turbocharged and intercooled diesel engines are specifically engineered for stationary diesel generators, providing reliable and stable power output for industrial and commercial applications. Featuring a robust engine block and efficient combustion systems, they are designed for continuous operation in demanding environments. With multiple configurations available, these engines offer a versatile solution for diverse power generation needs.
Performance Metrics
Standby Power Range
55 kW
Min Standby Power
180 kW
Max Standby Power
1,500 r/min
Rated Speed
Technical Specifications
Engine Model Specifications
| Model | Bore & Stroke (mm) | Displacement (L) | Intake Way | Standby Power (kW) |
|---|---|---|---|---|
| QC4115D | 115*135 | 5.61 | Naturally aspirated | 60 |
| QC4112D | 112*135 | 5.32 | Naturally aspirated | 55 |
| QC4112ZD | 112*135 | 5.32 | Turbocharged | 80 |
| QC4112ZLD | 112*135 | 5.32 | Turbocharged & Inter-cooled | 95 |
| QC6112ZLD | 112*135 | 7.98 | Turbocharged & Inter-cooled | 165~180 |
Engine Design
Fuel Consumption Ratios
- Standard Models: <= 205 g/kW.h
- High-Efficiency Models: <= 198 g/kW.h
- Cylinder Liner Type
- Wet
- Key Components
- TurbochargerIntercoolerRadiator CoolingFuel Injection SystemAir Intake Filter
Logistics
Packaging & Shipping
- Heavy-duty wooden crates
- Reinforced cardboard boxes
- Skid-mounted for easy transport
- Containerized international shipping
