Stainless Steel V-Wire Water Well Screen
This stainless steel V-wire screen is designed for water well applications. It provides sand control and efficient water extraction.
Technical Specifications
Product Overview
High-Efficiency Filtration
These continuous slot wire-wrap screens are essential components for water, oil, and gas well completions. Constructed by welding cold-rolled triangular V-shaped wire around a longitudinal array of support rods, these units offer exceptional structural strength with minimal weight. The design optimizes flow rates while effectively preventing sand and gravel ingress, ensuring long-term well productivity.
Technical Specifications
Dimensions
25 mm
Min Diameter
1,200 mm
Max Diameter
6 m
Max Length
End Connections
- Plain beveled ends
- Flanged
- Threaded couplings
Wedge Wire Dimensions
| Dimension | Available Range (mm) |
|---|---|
| Width | 1.50, 1.80, 2.30, 3.00, 3.30, 3.70 |
| Height | 2.20, 2.50, 2.70, 3.60, 4.30, 4.70, 5.60, 6.30, 7.00 |
- Materials
- Galvanized Low CarbonStainless Steel 304Stainless Steel 316
Performance
Key Advantages
Large open areaHigh filtering accuracyCustomizable designHigh strength-to-weight ratio
