Stabilized Soil Mixing Plant with Extra-Long Mixing Shaft
This stabilized soil mixing plant features an extra-long mixing shaft for even and efficient mixing. Patented technology ensures precise measuring for reliable performance.
Technical Specifications
Overview
High-Efficiency Stabilized Soil Mixing Solution
This stabilized soil mixing plant utilizes advanced double horizontal axis technology for superior mixing homogeneity and productivity. Engineered for demanding environments, it features modular construction for easy transport and set-up, alongside an extra-long mixing shaft that optimizes efficiency. With intelligent computer-controlled metering and automated frequency-regulated speed control, the system ensures precision in proportioning while maintaining energy-efficient operations.
Technical Specifications
Performance Metrics
300 t/h
Productivity (WBZ300)
600 t/h
Productivity (WBZ600)
60 mm
Max Aggregate Diameter
Operating Parameters
| Feature | Specification |
|---|---|
| Measuring method | Computer metering |
| Speed regulation | Frequency control |
| Control method | Manual/Automatic |
Accuracy
Measuring Accuracy
| Material | Accuracy |
|---|---|
| Aggregate | ±2% |
| Powder | ±1% |
| Water | ±1% |
Features
System Highlights
- Double horizontal axis mixing with no liner plate for balanced performance
- Electric lubrication pump with German-engineered axle end seals
- Intelligent electromagnetic flow meter for water supply
- Modular assembly structure for convenient disassembly and transport
- High-reliability electric components from international brands
