Solar Water Pump
This pump can be powered by AC and DC sources without modification. It is designed for solar deep well systems and features advanced rare earth permanent magnets.
Technical Specifications
Product Overview
High-Efficiency Solar Water Pump
This 4-inch AC/DC hybrid solar water pump is engineered for reliable, autonomous water extraction in remote or grid-independent locations. Featuring a brushless DC motor and built-in controller, it offers flexible power options and advanced protection mechanisms, including dry-running and over-voltage safeguards. Its robust design is optimized for deep well applications, providing a sustainable and cost-effective solution for agricultural, residential, and industrial water supply needs.
Performance Metrics
Maximum Head
75 m
Max Head
Maximum Flow Rate
90 L/min
Max Flow
Technical Specifications
- Power Rating
- 0.5 HP
- Max Input Power
- 1.2 kW
- Motor Type
- Water filled / BLDC
- Solar Panel Requirement
- 300W * 3
- Voltage Range
- DC: 60-380Vmp, AC: 90-240V
- Max VOC
- 440 V
Dimensions & Installation
- Pump Diameter
- 4 inch
- Discharge Size
- 1.25 inch
- Max Submergence Depth
- 150 m
Features & Protection
Key Features
- Hybrid AC/DC power operation
- Built-in frequency converter and controller
- Soft starting running
- Thrust bearing system
- Automatic running with self-control
Warranty
2 Years Warranty
- Protection Systems
- Dry-running protectionOver-current protectionInput Over-voltage ProtectionOverload protection
