Technical Specifications
Product Overview
Professional Silent Power Generation
This silent-type generator is engineered for reliable, high-efficiency power supply in noise-sensitive environments like residential areas or hospitals. Featuring a robust, weather-resistant, and dust-proof enclosure, it combines powerful performance with advanced sound-dampening technology for quiet operation. The unit is designed for ease of maintenance and secure transportation, making it a dependable choice for both prime and standby power applications.
Technical Performance
Operating Specs
175 kVA
ESP Rating
160 kVA
PRP Rating
400 V
Voltage
1,500 r/min
Speed
50 Hz
Frequency
Major Components
| Component | Specification |
|---|---|
| Engine | CUMMINS/6CTA8.3-G2 |
| Alternator | STAMFORD/UCI274F |
Physical Attributes
Size and Weight
- Weight: 3040 kg
- Dimensions: 3600 x 1333 x 2040 mm
Design and Safety Features
Maintenance and Portability
Rain-proofDust-proofForklift adapterExternal fuel filler
- Acoustic Features
- Residential silencersNoise reduction > 30dB(A)Flame retardant silencing cottonFully-closed design
