Self-Propelled Aerial Work Platform
This self-propelled aerial work platform offers exceptional maneuverability and reach for various elevated tasks. It features pothole protection.
Technical Specifications
Overview
Professional Aerial Work Platforms
These self-propelled aerial work platforms are engineered for versatile performance in both indoor and outdoor maintenance, installation, and repair tasks. Featuring a compact chassis and high maneuverability, they allow operators to navigate tight work environments with ease while maintaining excellent stability. With robust safety mechanisms like pothole protection, tilt alarms, and precise proportional controls, these platforms enhance operational efficiency and safety at height.
Performance
Key Performance Metrics
200 kg
Lifting Capacity
23 %
Gradeability
4.5 km/h
Driving Speed (Stowed)
Technical Specifications
Model Comparison
| Feature | IMP80J | IMP100J |
|---|---|---|
| Working Height (Max) | 8 m | 10 m |
| Platform Height (Max) | 6 m | 8 m |
| Weight | 2800 kg | 2870 kg |
| Driving Speed (Raised) | 0.7 km/h | 0.5 km/h |
- Safety Certifications & Features
- Pothole ProtectionEmergency StopTilt AlarmDescent Alarm
Physical Dimensions
Machine Dimensions
- Stowed Size: 2.76 x 0.99 x 1.99 m
- Platform Size: 0.91 x 0.85 x 1.14 m
- Wheelbase: 1.2 m
- Ground Clearance: 0.075 m
- Pothole Board Clearance: 0.025 m
- Turning Radius
- 1.82 m
Power and Drive
- Power Source
- 24V/240Ah Battery
- Tire Specifications
- 406 x 125 mm
