Self-Priming Centrifugal Oil Pump
This self-priming centrifugal oil pump features a simple construction and is easy to operate. It is designed for efficient fluid transfer in a wide range of applications.
Technical Specifications
Overview
High-Efficiency Self-Priming Solution
The CYZ series is a self-priming centrifugal oil pump designed for high displacement and superior efficiency in maritime and industrial applications. Its simple construction and easy operation make it a reliable choice for professional buyers needing a convenient, easy-to-repair pumping solution. This pump is specifically engineered to handle various fuels and liquids with a wide application scope, ensuring versatile performance across different operating environments.
Performance & Operation
Medium Temperature Range
-20 °C
Min Temperature
80 °C
Max Temperature
- Key Features
- Self-PrimingHigh EfficiencyHigh DisplacementSimple ConstructionEasy Operation
Application
Compatible Fluids
- Gasoline
- Kerosene
- Diesel Oil
- Seawater
- Fresh Water
Typical Applications
- Oil load and unload in boats
- Oil bunkers
- Oil tankers
- General fluid transfer
Technical Construction
Internal Components
- Suction room
- Liquid storage room
- Vortex room
- Liquid returning hole
- Gas and liquid dividing room
- Bearing Configuration
- Single row radial ball bearings
- Sealing System
- Mechanical seals on shaft end with high/low pressure area seal ring
- Cooling System
- Yes
- Cooling Specification
- Integrated cooling room in the bottom of the bearing stand
