Ricardo Diesel Engine for Industrial Applications
The Ricardo diesel engine is a robust and reliable power source designed for various industrial applications. This engine features a heavy-duty construction with a cast iron block and cylinder head, ensuring durability and longevity.
Technical Specifications
Product Overview
Industrial Power Solutions
The 4100D industrial diesel engine is a robust, four-stroke power source engineered for demanding environments. Featuring direct injection and turbocharging, it delivers consistent power for construction, agricultural machinery, and power generation. Its durable cast iron construction and liquid-cooling system ensure longevity and optimal thermal performance under heavy operational loads.
Technical Specifications
Performance Metrics
30 KW
Rated Power
1,500 RPM
Rated Speed
3.93 L
Displacement
19 :1
Compression Ratio
Engine Architecture
| Feature | Specification |
|---|---|
| Model | 4100D |
| Cylinder Count | 4 |
| Cooling Method | Water cooling |
| Combustion System | Direct injection |
| Inspiration | Turbo charging |
Physical Dimensions
- Bore: 100 mm
- Stroke: 115 mm
- Net Weight: 380 kg
- Overall Dimensions: 1000 x 600 x 1200 mm
Operational Details
- Operational Capabilities
- 12V/24V Electric startingCombined pressure and splash lubricationDirect injection system
- Fuel Consumption
- 258.4 g/kw.h
