Refrigerator Fan Motor
This motor is designed for refrigerator fan applications, ensuring efficient air circulation. It comes in AC and DC configurations, with customizable options for voltage, power, and lead wire specifications.
Technical Specifications
Product Overview
Versatile Refrigeration Cooling Solutions
This range of fan motors is engineered for diverse cooling applications including direct cooling, frost-free, and commercial refrigeration systems. Available in both AC (220V-240V) and DC (12V) configurations, these motors support various fan types such as centrifugal and square fans. Key features include adjustable speed controls, integrated temperature protection, and explosion-proof capabilities to ensure operational reliability.
Technical Specifications
Motor Categories
- Brushless Motor
- Shaded Pole Motor
- Square Fan
- Centrifugal Fan
- Electric Damper
- AC Input Voltage
- 220-240V / 50Hz / 60Hz120V / 60Hz
- DC Motor Advanced Features
- PWM ControlFG OutputSoft StartReverse ProtectionWaterproof
Mechanical Details
Bearing Types
Sleeve BearingBall BearingSelf-lubricating
DC Wiring Configuration
| Wire Color | Function |
|---|---|
| Red | Positive Power |
| Black | Negative Power |
| Purple | FG Output |
