PVC Pipe Extrusion Line
This PVC pipe extrusion line efficiently produces pipes ranging from 16mm to 63mm. It features a twin-screw extruder, vacuum forming table, haul-off unit, cutter, and stacker.
Technical Specifications
Product Overview
High-Efficiency Double Pipe Extrusion Line
This double pipe extrusion line is engineered for the high-speed production of PVC and UPVC pipes ranging from 16mm to 110mm. The system integrates a conical twin-screw extruder, precision vacuum forming, and automated haul-off and cutting units to ensure consistent quality and high output. Designed for ease of operation, it features advanced inverter technology and precise temperature control for reliable industrial performance.
Technical Specifications
Performance Metrics by Model
| Model | Pipe Range (mm) | Max Capacity (kg/h) | Total Power (kW) |
|---|---|---|---|
| KBLD-40PVC | 16-40 | 180 | 75 |
| KBLD-63PVC | 16-63 | 300 | 95 |
| KBLD-110PVC | 50-110 | 600 | 145 |
- Core Components
- Conical twin-screw extruderDouble output mouldVacuum forming tableDouble haul-offAutomatic cutterStacker
Key Features
Operational Efficiency
600 kg/h
Max Capacity
10 m/min
Max Traction Speed
24 m
Max Line Length
Automation & Control
- Automatic fault alarm system
- PLC automatic control system
- High-precision temperature controllers
- Variable frequency inverter drive
Compliance & Services
Quality Certifications
SGS CertifiedISO 9001:2000
Turnkey Support Services
- Factory layout planning
- Raw material sourcing assistance
- On-site installation and training
- 1-year quality guarantee
- Lifetime after-sales support
