PVC Double Pipe Extrusion Line (Φ16-63mm)
This PVC double pipe extrusion line includes a conical twin screw extruder and a vacuum forming table. It is designed for producing PVC/UPVC pipes ranging from Φ16-63mm.
Technical Specifications
Product Overview
High-Efficiency Double Pipe Extrusion
This PVC double pipe extrusion line is a complete, automated system designed for high-capacity manufacturing of pipes ranging from 16mm to 63mm. The production line integrates a twin-screw extruder with precise temperature control and an automated vacuum forming, cooling, and cutting process. Built for reliability, it features high-degree automation, fault alarm systems, and easy maintenance for long-term industrial service.
Technical Parameters
Performance Comparison
| Specification | KBLD-40PVC | KBLD-63PVC | KBLD-110PVC |
|---|---|---|---|
| Pipe Range (mm) | 16-40 | 16-63 | 50-110 |
| Max. Capacity (kg/h) | 180 | 300 | 600 |
| Max. Traction Speed (m/min) | 10 | 10 | 8 |
| Motor Power (kw) | 22 | 37 | 75 |
| Line Length (m) | 19 | 20 | 24 |
| Total Power (kw) | 75 | 95 | 145 |
System Components
Line Components
- Conical twin screw extruder
- Double output mould
- Vacuum forming table
- Double haul-off unit
- Cutter
- Stacker
Features & Technology
- Control & Automation
- Automatic Fault AlarmHuateng InverterRKC Temperature ControllerOmron Temperature ControllerHigh Automation
Business Information
Trading Details
MOQ: 1 SetPayment: T/TFOB ShundeCustomization Available
Compliance
- Quality Standards
- SGSISO9001:2000
