PVC Cable Trunking Extrusion Line
This PVC cable trunking extrusion line includes a conical twin-screw extruder, vacuum forming table, haul-off machine, cutting machine, and stacker. It is designed for PVC material with a production diameter range of Φ 16-Φ 40mm.
Technical Specifications
Product Overview
Professional PVC Trunking Extrusion Line
This advanced extrusion line is engineered for the high-capacity, automated production of PVC trunking and pipes. The system integrates a conical twin-screw extruder with precise vacuum forming and cutting units, ensuring consistent material flow and optimal melt quality. Designed for reliability and ease of maintenance, the line features automated fault alarms and high-performance components suitable for continuous industrial operation.
Core Specifications
Production Capacity
150 kg/h
Minimum Capacity
180 kg/h
Maximum Capacity
- Production Diameter Range
- 16mm - 40mm
- Vacuum Forming Table Length
- 3500 mm
Performance Data
Performance Comparison
| Specification | Double Line | Single Line |
|---|---|---|
| Haul-off speed | 0-12 m/min | 0-10 m/min |
| Installation power | 63 kw | 62 kw |
| Total length | 18 m | 19 m |
System Components
Production Line Configuration
- KBL55/113 Conical Twin Screw Extruder
- Extrusion Die
- Vacuum Calibration Cooling Tank
- Haul-off Machine
- Cutting Machine
- Stacker
Features
- Operational Advantages
- High CapacityAutomated Fault AlarmSimple MaintenanceHigh AutomationConsistent Quality
