Pneumatic Y-Type Tank Discharge Valve
Pneumatic Y-type tank discharge valves facilitate the rapid removal of material or samples from reactors, drains, and vessels. These valves can be welded or flanged to the vessel bottom, commonly installed for feeding vessels or draining pipelines.
Technical Specifications
Product Overview
Industrial Tank Bottom Angle Valve
This pneumatic Y-type tank bottom angle valve is engineered for high-performance material discharge in critical industrial vessels. Featuring a dead-space-free design and robust protection plating, it offers superior resistance to erosion and corrosion in demanding applications. The unit supports versatile installation with multiple outlet angles and is designed to provide reliable, remote-controlled operation for slurry and chemical processing.
Technical Specifications
Available Outlet Angles
- 45
- 50
- 90
- Size Range
- DN50 to DN350 (NPS2 to NPS14)
- Pressure Class
- Class 150Class 300
- Max Temperature
- 425 ℃
Design and Materials
Operating Modes
PneumaticManualElectric
- Body Materials
- Carbon SteelStainless Steel
- Sealing Surface Material
- Cemented carbide or Tungsten carbide overlay
Standards and Compliance
Industry Standards
| Category | Standard |
|---|---|
| Flange Connection | ASME B16.5, GB/T9113 |
| Design Standard | ASME B16.34 |
| Pressure Test | GB/T13927, API598 |
Applications
Recommended Industries
- Petrochemical
- Alumina
- Steel
- Polymer
- Mining
- Pharmaceutical
- Fine Chemicals
