Pneumatic Ceramic Swing Gate Valve for Abrasive Materials
This pneumatic ceramic swing gate valve is designed for pressurized and vacuum systems. The ceramic sealing faces are ground and polished to ensure reliable sealing performance.
Technical Specifications
Product Overview
Industrial Performance for Abrasive Media
This pneumatic ceramic swing gate valve is engineered specifically for handling abrasive materials in demanding industrial environments. Featuring toughened engineering ceramic sealing faces, it offers exceptional abrasion resistance and an extended service life compared to standard valves. The unique swing gate design prevents ash deposition and material accumulation, ensuring reliable operation even in challenging conditions like steel plants, cement transport, and power generation systems.
Technical Specifications
Operating Temperature
0 °C
Min Temp
200 °C
Max Temp
Operating Mode
Pneumatic
- Size Range
- NPS4 to NPS12 / DN100 to DN300
- Pressure Range
- Class 150PN6PN10
- Connection Type
- Flange
Design & Construction
Key Design Advantages
- Cylinder piston rod isolated from media for longer life
- Rotational disc motion prevents ash deposition
- Slant structure outlet prevents material accumulation
- Floating spring connection for automatic wear compensation and thermal expansion
- Sealing Material
- Toughened Engineering Ceramics
Compliance & Standards
Industry Standards
| Category | Standard |
|---|---|
| Pressure Test | GB/T13927, API598 |
| Face to Face | GB/T12221, API609 |
| Valve Body | GB/T12224, ASME B16.34 |
Applications
- Suitable Industries
- Steel PlantsCereals TransportCement TransportCoal Fired Power Plants
