Photovoltaic Solar Module
Photovoltaic solar modules convert sunlight into electricity. These modules are designed for system stability with a power generation efficiency attenuation that shall not exceed 20% over 25 years.
Technical Specifications
Product Overview
High-Efficiency Solar Power
This advanced monocrystalline photovoltaic module is engineered for high-yield energy conversion in residential, commercial, and utility-scale projects. Designed for durability and stability, it features a robust frame and advanced cell technology that ensures consistent power generation even under varied environmental conditions. With an impressive 19.8% conversion efficiency, it provides a reliable, maintenance-free solution for long-term sustainable energy integration.
Technical Specifications
Performance Metrics
400 W
Peak Power
42.29 V
Best Working Voltage
9.46 A
Best Working Current
19.8 %
Conversion Rate
Voltage & Current Ratings
| Parameter | Value |
|---|---|
| Open Circuit Voltage | 49.10 V |
| Short Circuit Current | 10.35 A |
| Maximum System Voltage | 1500 V DC |
| Maximum Protection Current | 20 A |
Construction & Durability
Physical Dimensions
| Attribute | Measurement |
|---|---|
| Cell Type | Mono-crystalline |
| Cell Quantity | 144 (6*24) |
| Dimensions | 2014mm * 1002mm * 35mm |
| Weight | 22.5 kg |
Environmental Resilience
- Operating Temperature: -40°C to +85°C
- Rated Operating Temperature: 45±2°C
- Open Circuit Voltage Temperature Coefficient: -0.34%/°C
- Short Circuit Current Temperature Coefficient: +0.05%/°C
- Peak Power Temperature Coefficient: -0.46%/°C
System Benefits
- Core Advantages
- System StabilityMaintenance FreeArchitectural IntegrationLow Attenuation
