Permanent Magnet Brushless Synchronous Motor
This permanent magnet brushless synchronous motor is designed for demanding industrial applications. These motors offer exceptional torque density, precise speed control, and reliable performance.
Technical Specifications
Overview
High-Efficiency Synchronous Motor
This permanent magnet brushless synchronous motor is designed for reliability and efficiency across industrial and agricultural applications. Featuring a robust construction and advanced cooling, it offers superior performance with low maintenance requirements. The motor is engineered for long service life, making it a dependable choice for general drive systems and diverse operational fields.
Technical Specifications
Key Performance Metrics
0.75 kW
Power (50Hz)
1,380 rpm
Speed (50Hz)
0.78 Cos φ
Power Factor
72 %
Efficiency (Full Load)
Protection Class
IP55
- Operating Conditions
- S1 DutyThree-PhaseIndustrial Grade
Performance Data
Frequency Performance Comparison
| Frequency | Power (HP) | Speed (rpm) | Efficiency (%) |
|---|---|---|---|
| 50Hz | 1 | 1,380 | 72 |
| 60Hz | 1.15 | 1,650 | 72 |
Mechanical Details
Bearing Specifications
- Drive End (DE): 6204
- Non-Drive End (NDE): 6204
