Technical Specifications
Overview
High-Performance Outdoor Display
The P4 Outdoor LED Advertising Screen is a robust, high-brightness display solution engineered for reliable visual communication in demanding outdoor environments. With a 4mm pixel pitch and 3840Hz refresh rate, it delivers exceptional image clarity and smooth motion for advertising and public information. Its IP65-rated waterproof construction and lightweight die-casting aluminum cabinets ensure durability, easy installation, and long-lasting performance in various weather conditions.
Technical Specifications
- Pixel Pitch
- 4 mm
- Pixel Density
- 62500 dots/m2
- LED Type
- SMD1921
- Refresh Rate
- 3840 Hz
- LED Drive Scan
- 1/8 scan
Performance Metrics
Display Performance
5,000 CD/m2
Brightness
Power Consumption
| Metric | Value | Unit |
|---|---|---|
| Maximum | 900 | W/Cabinet |
| Average | 450 | W/Cabinet |
Physical Characteristics
Dimensions
- Module Size: 256*128 mm
- Cabinet Size: 1024*768 mm
- Cabinet Weight
- 27 Kg
- Material
- Die-casting Aluminum
Features
Key Features
WaterproofIP65 RatedFast Lock SystemOutdoor Ready
