Motorcycle Brake Caliper
These motorcycle brake calipers are engineered to provide reliable stopping power. They are available in various mounting positions, pitch joint dimensions, caliper diameters, and pad areas.
Technical Specifications
Product Overview
High-Performance Motorcycle Brake Calipers
This collection of motorcycle brake calipers is engineered for reliability and precise braking performance. Available in various configurations, these units cater to different mounting requirements, including both left and right-side positions. With diverse pitch joint dimensions, caliper diameters, and pad area specifications, these components are designed to integrate seamlessly into a wide range of motorcycle braking systems.
Technical Specifications
Model Specifications
| Model ID | Position | Pitch Joint (mm) | Caliper Diameter | Pad Area (mm²) |
|---|---|---|---|---|
| 710182000 | Left | 45 | Φ30.2mm | 1,108 |
| 710042000 | Left | 65 | Φ34mm | 1,233 |
| 710092000 | Right | 45 | Φ30.2mm | 1,170 |
| 763152000 | Left/Right | 87.7 | 6 x 25mm | 3,162 |
| 817182000 | Left | 17 | Φ38.2mm | 1,512 |
| 710172000 | Left | 49 | Φ34mm | 1,484 |
| 724262000 | Left | 42.8 | 2-32mm | 1,072 |
| 710232000 | Left | 92.5 | Φ27mm | 1,090 |
| 714432000R | Right | 53 | Φ42.8mm | 1,542 |
| 721358000 | Right | 85 | 2 x 25mm | 1,408 |
| 723982000 | Left | 84 | 2 x 32mm | 1,589 |
Key Metrics
Performance Range
17 mm
Min Pitch Joint
92.5 mm
Max Pitch Joint
1,072 mm²
Min Pad Area
3,162 mm²
Max Pad Area
