Technical Specifications
Overview
High-Efficiency Monocrystalline Solar Solutions
These A-grade monocrystalline solar panels are engineered for high-efficiency energy conversion in residential and commercial applications. Designed to withstand harsh environmental conditions, they offer a robust construction that ensures long-lasting performance and reliable power output. With a wide range of wattage options from 300W to 370W, these modules are ideal for maximizing energy production even in limited installation spaces.
Key Performance Metrics
Performance Highlights
370 W
Max Power
1,500 V
System Voltage
19 kg
Module Weight
Technical Specifications
Model Performance Data
| Model | Wattage (W) | Voc (V) | Vmp (V) | Isc (A) |
|---|---|---|---|---|
| KD-M300 | 300 | 44.62 | 37.62 | 8.56 |
| KD-M330 | 335 | 46.73 | 38.09 | 9.32 |
| KD-M350 | 350 | 47.37 | 38.55 | 9.55 |
| KD-M360 | 360 | 47.2 | 38.9 | 9.79 |
| KD-M370 | 370 | 47.55 | 39.21 | 9.94 |
Physical Characteristics
Application Class
Class A
- Dimensions
- 1958 x 992 x 40 mm
- Solar Cell Technology
- Monocrystalline 156*156 Cells
Operating Conditions
- Operating Temperature
- -40°C to +85°C
- Nominal Operating Cell Temp (TNOCT)
- 48 °C
Compliance & Certification
- Industry Certifications
- TUVIEC61215IEC61730CEPIDISOINMETRO
