Monocrystalline Double Glazing Solar Panel
This monocrystalline solar panel features 60 cells with dimensions of 1658*992*6.5mm or 1658*992*35mm. It has advanced surface treatment and a 5BB cell design to reduce series resistance and improve module efficiency.
Technical Specifications
Overview
High-Efficiency Double Glazing Module
This monocrystalline solar module features a robust double-glazing design, significantly enhancing durability, weather resistance, and long-term power output stability. Engineered with advanced surface treatment and 5BB cell technology, it minimizes resistance and maximizes light absorption to achieve module efficiency up to 19.5%. It is a versatile solution suitable for residential, commercial, and industrial solar energy systems.
Technical Specifications
- Cell Technology
- Monocrystalline PERC
- Cell Size
- 156.75 x 156.75 mm
- Number of Cells
- 60
- Power Tolerance
- 0 ~ +5W
- Maximum System Voltage
- 1000V / 1500V DC
- Operating Temperature Range
- -40°C to +85°C
- Nominal Operating Cell Temperature (NOCT)
- 45°C ± 2°C
Performance Metrics
Electrical Characteristics (STC)
| Parameter | 300W | 310W | 320W |
|---|---|---|---|
| Open-Circuit Voltage (Voc) | 39.5V | 39.8V | 40.5V |
| Short-Circuit Current (Isc) | 9.69A | 9.87A | 10.39A |
| Optimum Operating Voltage (Vmp) | 33.0V | 33.8V | 33.6V |
| Optimum Operating Current (Imp) | 9.10A | 9.18A | 9.54A |
| Module Efficiency | 18.2% | 18.8% | 19.5% |
Key Performance Indicators
320 W
Max Power Output
19.5 %
Max Efficiency
15 A
Max Series Fuse
